Model: 26"x17" Falcon Orchid
Type: 26" Steel Rigid MTB
Speed: 18 Speed Revoshift
Frame: 26"x17"mm Rigid Boys Frame, HI-TEN STEEL,TIG WELDED, Direct Mount Rear End, H/T: 30x34mmx120mmL, Seat clamp With welded
Fork: 26" Steel SUS FORK, Steerer tube: 25.4x22.2x153mmL, Steel black Crown and Stanchion with V-Brake Pivot
Head Badge: Printed with Decals
Headset: Steel 1”x24T, 22.2*30*27, ball retainer 5/32"x16x2pcs, Set of 8Pcs
B. B. Set: BSA 1.37"x24T with BB axle
B.B Axle: Steel cotterless, Bolt type axle, Long side forword
B. B Cable Guide: Plastic for 40mm BB Shell
Decals: SKC Decals as per artwork
Seat Bolt/Pin/Clamp: Steel seat bolt M8*40mm with Dome Nut
Handle Bar Steel. Diameter: 22.2, Barbore-25.4mm. Width: 580mm. Rise: 30mm. Back Sweep 15°.
Stem Steel MTB Type, Quill OD-22.2mm x150mmL, Ext: 100mm, Rise: 25deg, Barbore: 25.4mm, with Allen type expander bolt and plastic cap
Grips TPR MTB Type 90mm/90mm (One side Opened)
Brake Levers Full Resin Brake Lever, 3 Finger Type
Front Brake Steel V-Brake , Arm :110mm , brake shoe-60мм EN Std., Linear spring type. Replace flat washe out side to inside.
Rear Brake Steel V-Brake , Arm :110mm , brake shoe-60мм EN Std., Linear spring type
Brake Inner Cable 1.5*1100MM-7*8 HEAD, steel galvanized
Brake Inner Cable 1.5*1900MM-7*8 HEAD, steel galvanized
Brake Outer Casing 2P, 5mm, 500M/Roll
Shifter Right 6 SPEED BLK INDEX TWIST SHIFTER
Shifter Left 3 SPEED FRICTION TYPE TWIST SHIFTER
Front Derailleur Down pull 28.6 mm Clamp. For 42-34-24T Chainset.
Rear Derailleur REAR DERAILLEUR, TOURNEY TZ, RD-RD-TZ500, GS 6-SPEED, BRACKET TYPE BULK
Chain Steel 1/2'' x 3/32'' Links, 6/Speed, 108 link
Freewheel 6 Speed Index 14-28 T
Chainwheel Steel triple chainwheel 3/32"x24x34x42T, 24T Black, 34T Silver, 42T Black, 170mm Steel without plastic coated.Black Spider, Guard Blk.
Pedals 9/16" Boron Axle with PP body and BS Reflectors & Ball bearing,warning decals (R+L)
Derailleur Cables Outer Casing SP 4mm
Brake Outer Casing endcap Steel 5mm
Derailleur Outer Casing endcap Plastic 4mm
Inner safety endcap Alloy
ReflectorBracket(F) Front Reflector, Clear, Snap on
Reflectors(Front) Front Reflector, Clear, Snap on
Reflector Bracket(R) Seat Post braket, 28.6mm
Reflectors(Rear) Rear Reflector, Red, Snap on
Reflectors(Wheel) Wheel Reflector, Clear,W/14GA. Rivet, BS Std
Tyres Front 26"x1.95" City Pattern tyre
Tyres Rear 26"x1.95" City Pattern tyre
Tubes/Valve 26"x1.95" Butyle tube with AV 40L Valve
Rim Tape 26" Rubber
Rims 26"x1.75 Alloy 14Gx36 Holes Double Wall with side CNC
Front Hub Steel 14Gx3/8"x36Hx100x140mm, Black Flange Nut with Safety washer
Rear Hub Steel 14G X 3/8" X 36H X 130 X 170mm,Black Flange Nut with Serated washer
Spokes Steel 14Gx263mmL
Spokes Steel 14Gx 260/262mmL
Spoke Disc PVC 5 1/2"
Nipples Standard
Saddle MTB type Saddle, Steel Rails & Clamps BK With Bk Bumper
Seat Post Suspension seat post, Steel 25.4mmx 1.6mm x300mmL.
Water Bottle Bolt Steel Allen bolt M5x12mm
Bell Alloy top with Resin bracket
Manual Manual - as Buyer AW
Tools 5/6mm Steel Allen Key
Tools Steel Multispanner
Carton Standard 5 Ply, 85% Assembly (Carton Size:mm)
Fork Protector Plastic # 6 (1pc Each Cycle)
Axle Protector Plastic # 11 ( Each Bike 2 Pcs)
Axle D/T Protector Plastic # 14 ( Each Bike 1 Pc)
Front Axle Protector Each Bike 1 Pc
Seat tube Protector Each Bike 1 Pc
Head Tube Protector Each Bike 1 Pc
Wrapping Paper 2 Ply corrogated
WRAPPING BOARD: Per bike 01 pcs
Adhesive Tape: Use Masking Tape for wrapping
Long Cable ties: Plastic Cable Tie, 420mmL
Warning decals: PVC Printing
Staples: Steel
Strapping: 12mm x 1mm
Color: Mixed (As given picture).
